TP Link TL-SG2210P
Artikelnummer 396785
** Hierbei handelt es sich um ein Pflichtfeld.
TP Link TL-SG2210P
TP Link TL-SG2210P, 8-Port-Gigabit-Smart-PoE-Switch mit 2 SFP-Slots
Der TL-SG2210P hat 8 Gigabit-LAN-Ports, die zusammen 53W PoE-Leistung bieten, um PoE-kompatible Geräte wie Accesspoints oder IP-Kameras mit Strom zu versorgen. Außerdem hat er zwei SFP-Slots für mehr Flexibilität in Ihrem Netzwerk. Der PoE-Switch unterstützt viele QoS-Funktionen sowie erweiterte Sicherheitsfunktionen und Layer-2-Managementfunktionen. Er ist daher sehr geeignet für kleine und mittlere Unternehmen, die ein einfaches und effizientes Management wünschen.
Eigenschaften:
- 8x Gigabit-LAN-PoE-Ports
- 2x SFP-Ports
- 802.3af-kompatibles PoE mit einer Gesamtleistung von 53 W
- Integrierte Sicherheitslösung mit 802.1Q-VLAN, ACL, Port-Sicherheit und Storm Control
- L2/L3/L4-QoS und IGMP-Snooping für optimierte Sprach- und Videoanwendungen
- Management über WEB, CLI, SNMP und RMON
- Geeignet für Enterprise Nutzung
Technische Daten:
Standards und Protokolle:
- IEEE802.3i
- IEEE802.3u
- IEEE802.3z
- IEEE802.3ab
- IEEE802.3ad
- IEEE802.3af
- IEEE802.3x
- IEEE802.1d
- IEEE802.1s
- IEEE802.1w
- IEEE802.1q
- IEEE802.1p
Schnittstelle:
- 8x 10/100/1000Mbit/s-RJ45-PoE-Ports mit Autoabstimmung und Auto-MDI/MDIX
- 2x 1000Mbps-SFP-Slots
Kabel:
- 10BASE-T: UTP-Kategorien 3, 4, 5 (max. 100m)
- 100BASE-TX: UTP-Kategorie 5 oder höher (max. 100m)
- 1000Base-T: UTP-Kategorie 6 oder höher (max. 100m)
- 1000BASE-X: MMF, SMF
Stromversorgung:
- 100 - 240 V
PoE-Ports:
- Standard: IEEE802.3af
- Ports: 8
- Leistungsabgabe: 53W
Energieverbrauch:
- Mit PoE: Max. 63,4W (230V/50Hz)
- Ohne PoE: Max. 10,4W (230V/50Hz)
Leistung:
- Switchingkapazität: 20 Gbps
- Switchingkapazität: 20 Gbit/s
- Paketweiterleitungsrate: 14,9 Mpps
- MAC-Adresstabelle: 8k
- Paketpufferspeicher: 512kB
- Jumbo-Frames: 9216 Bytes
Abmessungen / Montage:
- Abmessungen: 209 x 126 x 26 mm
- Desktop oder Wandmontage möglich
Typ: Switch
Anzahl Gigabit-Ports RJ45: 8
Anzahl SFP Ports: 2
Jumbo Frame: 9K (max.)
PoE (Power over Ethernet): Ja
IEEE 802.1p Quality of Service (QoS): Ja
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP): Ja
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP): Ja
IEEE 802.1D MAC Bridges: Ja
IEEE 802.1Q Virtual LANs (VLANs): Ja
IEEE 802.3ab 1000-BASE-T, Gigabit Ethernet: Ja
IEEE 802.3ad Link Aggregation Control Protocol: Ja
IEEE 802.3af Power Over Ethernet (PoE): Ja
IEEE 802.3u 100-BASE-TX, Fast Ethernet: Ja
IEEE 802.3x Flow Control (Full-Duplex Flow Control): Ja
IEEE 802.3z 1000-BASE-SX, Gigabit Ethernet: Ja
Wandmontage möglich: Ja
Farbe: schwarz
Breite (mm): 209
Höhe (mm): 26
Tiefe (mm): 129
